SafanDarley is adding a new machine to its Hybrid brake press range with a working length of 2050 mm. This model is available with a pressing force of 110 or 170 tonnes. According to the company, the machine is compact, fast and suitable for bending small, complex, thick sheet-metal parts.

Compared with traditional hydraulic brake presses, the introduction of the new machine significantly increases the pressing capacity for each available bending length. In turn, a wide range of possibilities are available for this machine concept. This brake press can, in fact, generate a pressing force of 110 and 170 tonnes across a bending length of approximately 2 m, making it suitable for companies with limited space. Furthermore, smaller, thick sheet-metal parts no longer have to be produced on excessively long brake presses, thus improving the efficiency and usability of the machinery.
The H Brake Hybrid is characterised by its novel hybrid concept; a combination of hydraulics and electronics. A servomotor with direct drive provides efficiency and speed, while hydraulics deliver the force and sustainability. The hybrid drive is only activated when the foot pedal is operated (the pump is stationary during the intervening period). Thanks to its dynamic Y axis, with approach and return speeds of 230 mm/sec, cycle times are achieved some 30% shorter than those of traditional hydraulic brake presses, says the company.
For further information www.safandarley.com
