Fast and simple tooling data solution

CNC Software Inc, developer of Mastercam, has collaborated with carbide tooling specialist Widia, to provide a solution that enables CAM users to quickly import tool assemblies from Widia Novo directly into Mastercam 2018.

Mastercam developers worked closely with Widia to let users import 3D tool assemblies directly into Mastercam, validate them, and save them in their Mastercam file and/or tool library. Features such as automated filtering ensure that the holders and tools which are selected can work together for the particular job. Users of Mastercam benefit from having the correct tooling for the material and type of machining operation, plus an accurate 3D model that can be used for visualisation and collision checking, in addition to the time savings.
“We found that in the past, our customers complained of having to search through big complicated catalogues to find related parts, then having to request or build the assemblies from scratch for use in systems such as Mastercam,” says Rich Taft, product owner at CNC Software. “With the integration of Widia Novo and Mastercam, customers save significant time searching for desired tools and building 3D tool assemblies that can be brought directly into Mastercam for easy use by most shops.
“Accurate tool definitions are a critical factor in modern CAM applications. Tool-path algorithms take advantage of these definitions to provide safe and efficient motion. In addition, the models that we import from Widia Novo help us to generate accurate in-process stock models that can be leveraged in subsequent operations. Customers can also make use of these models in verification and machine simulation to catch programming errors before the program ever gets to the machine tool.”
